FZKJ-RE-1：20ft Refrigerated Container+PV+Energy Storage System
● Equipped with high-efficiency refrigeration. ● The retractable PV panels adapt to varying sunlight conditions and weathers.
|
battery |
|
|
Battery type |
LiFePO4 |
|
Battery voltage range （V) |
44-58 |
|
Maximum charging and discharging current （A） |
180 |
|
Battery cluster capacity（KWH） |
48、(16*3） |
|
Communication method |
RS485、CAN |
|
Photovoltaic input |
|
|
Recommended maximum power （KW） |
8.58 |
|
Photovoltaic voltage range（V) |
576 |
|
Maximum input current（（A） |
18 |
|
Maximum number of input series （PCS） |
1 |
|
Communication output |
|
|
PCS Rated power（KW) |
15 |
|
Output voltage（V) |
380/400 |
|
Output frequency（Hz） |
50/60 |
|
Power factor |
＞0.99 |
|
Communication output |
|
|
Input voltage （V) |
380(-20%～+15%) |
|
Maximum input current （A) |
25 |
|
Input frequency （Hz） |
50Hz/60Hz±2.5Hz |
|
Standard parameters |
|
|
Size |
20 |
|
Power of refrigeration compressor（KW) |
8 （380V） |
|
Refrigeration temperature（°C） |
0°C-15°C |
|
Protection level |
IP55 |
|
Noise（dB） |
70 |
|
Communication method |
CAN、RS485、WIFI、4G |
|
Certification standards |
/ |
