KN110-10A

Urban commuting, short-distance travel,Lightweight and flexible, low fuel consumption

Urban commuting, short-distance travel
Lightweight and flexible, low fuel consumption

PRODUCT PARAMETERS

ENGINE TYPE 110cc,air-cooled,4 Stroke
Displacement	119.6ml
Bore&Stroke	52.4×55.5mm
Compression Ratio	9.0:1
Max Power(Kw/rpm)	5.3Kw/8000(r/min
Max Torque(N.M/rpm)	8.0N.m/6000rpm
Max Speed	75kmph
Accelerate	15s
Beyond the acceleration	14s
Engine Oil	1.0L
Clutch Type	Multi-disc wet clutch,automatic
lgnition	CDI
Spark plug	A7TC
Starting System	Electric+Kick start
Transmission System	Chain drive
Final drive ratio	14:38
Size	1930×700×1160mm
Seat Height	770mm
Wheelbase	1240mm
Min.Ground Clearance	160mm
Max.Permissionable	150Kg
Steering Angle how	35
How the side stand tilt Angle	13
Rider Capacity	1 Person
Dry.Weight	95kg
Fuel Tank Capacity	4L
Brakes Front	Disc Brake
Brakes Rear	Drum Brake
Front Tire	2.50-17
Rear Tire	2.75-17
Battery	12V/5Ah
40HQ(SKD)	105
40HQ(CKD)	188
